To override firewall rules at the Edge level, click New Rule under Firewall Rules, and follow the steps in Configure Firewall Rules. Optionally, at the edge level, you can override the inherited profile firewall rules. The following figure illustrates the 1:1 NAT configuration.

Enter the Allowed Traffic Source (Protocol, Ports, Remote IP/Subnet) details for the mapping in the respective fields.

Select the Outbound Traffic checkbox, if you want to allow the Outbound traffic that comes to the edge from Internet to the LAN Client to pass over the firewall connection.

In the Inside (LAN) IP text box, enter the actual IP (LAN) address of the host.

From the Interface drop-down menu, select the WAN interface where the Outside IP address will be bound.

In the Outside IP text box, enter the IP address with which the host can be accessed from an outside network.

In the Name text box, enter a name for the rule.To configure a 1:1 NAT rule, provide the following details. The '+' icon on the right can be used to add additional 1:1 NAT settings. Within each mapping, you can specify which ports will be forwarded to the inside IP address. Each mapping is between one IP address outside the firewall for a specific WAN interface and one LAN IP address inside the firewall. It can also translate outside IP addresses in different subnets than the WAN interface address if the ISP routes traffic for the subnet towards the SD-WAN Edge. These are used to map an Outside IP address supported by the SD-WAN Edge to a server connected to an Edge LAN interface (for example, a web server or a mail server). The following figure illustrates the port forwarding configuration. If you do not specify any IP address, then it will allow any traffic. In the Remote IP/subnet text box, specify an IP address of an inbound traffic that you want to be forwarded to an internal server.From the Segment drop-down menu, select a segment the LAN IP will belong to.In the LAN IP and LAN Port text boxes, enter the IP address and port number of the LAN, where the request will be forwarded.In the WAN Ports text box, enter one WAN port or range of ports separated with a dash (-), for example 20-25.

In the Outside IP text box, enter the IP address using which the host (application) can be accessed from the outside network.From the Interface drop-down menu, select the interface for the inbound traffic.From the Protocol drop-down menu, select either TCP or UDP as the protocol for port forwarding.

In the Name text box, enter a name (optional) for the rule.To configure a port forwarding rule, provide the following details. Port forwarding rules can be configured with the Outside IP which is on the same subnet of the WAN IP. Optionally, you can also restrict the inbound traffic by an IP or a subnet. Port forwarding rules enable you to configure rules to redirect traffic from a specific WAN port to a device (LAN IP/ LAN Port) within the local subnet. Access can be made available through either Port Forwarding Rules or 1:1 NAT (Network Address Translation) rules. Port Forwarding and 1:1 NAT firewall rules gives Internet clients access to servers connected to an Edge LAN interface. Note: You can configure Port Forwarding and 1:1 NAT rules individually only at the Edge Level.
